2PCTHREAD BALLVAVLE WITH ISO5211 PAD(1000WOG)
2PCTHREAD BALLVAVLE WITH ISO5211 PAD(1000WOG)
2PCTHREAD BALLVAVLE WITH ISO5211 PAD(1000WOG)
Applicature water、steam、oil、viscous media Anti-static,blow-out proof stem Torque balance，Daikin/3M seal
Investment casting,casting passed Germany TUv certification Material:CF8/CF8M/CF3/CF3M/WCB(customizable)
STANDARD SPECIFICATION
Pressure/Temperature: ASME B16.34 Design:ASME B16.34
Structure length: factory standard Test:API 598
Connection:BSP/BSPT/NPT/G/Rp/Rc
3PC FLANGED BALL VALVE WITHISO5211 PAD
Applicable water、steam,oil、viacous medea Fire prevention and anti-static,blow-out proof stem
Torque balance ,Three piese valve design, easy to install and repair Investment casting;casting passed Germany TUV certification Material:CF8/CF8M/CF3/CF3M/WCB(customizable)
STANDARD SPECIFICATION
Pressure/Temperature: ASME B 16.34 Design:EN12516-1
Structure length:DIN3202 Test:EN-12266-1
Connection:DIN2633
3PC THREAD BALL VALVE WITH ISO5211 PAD(1000WOG)
Applicable water,steam、oil、viscous media Anti-static,blow-out proof stem
Torque balance ,three piece body, easy to install and repair investment casting,casting passed TUV certification Material:CF8/CF8M/CF3/CF3M/WCB(customizable)
STANDARD SPECIFICATION
Pressure/Temperature: ASME B16.34 Design:ASME B16.34
Structure length:factory standard Test:API598
Connection:BSP/BSPT/NPT/G/RP/RC
3PC BUTT WELDING BALL VALVE WITH ISO5211 PAD(1000WOG)
Applicable water、steam、oil、viscous media Anti-static,blow-out proof stem
Torque balance,three piese valve design,easy to install and repair Investment casting.casting passed Germany TUv certification Material:CF8/CF8M/CF3/CF3M/WCB(customizable)
STANDARD SPECIFICATION
Pressure/Temperature:ASME B16.34 Design:ASMEB16.34
Structure length:factory standard Test:API598
Connection type:ASME B16.25
3PC SOCKETWELDING BALLVALVE WITHISO5211 PAD(1000WOG)
Applicable water、steam、oil、viscous media Anti-static,blow-out proof stem
Torque balance,three piece body design,easy to intall and repair Investment casting. casting passed Germany TUV certification Material:CF8/CF8M/CF3/CF3M/WCB(customizable)
STANDARD SPECIFICATION
Pressure/Temperature;ASME B16.34 Design: ASME B16.34
Structure length:factory standard Test:API598
Connection:GB/T 14383/ASME B16.11
3PCCLAMP BALL VAVLE WITH ISO5211 PAD
Applicable water、steam、oil、viscous media Anti-static,blow-out proof stem
Torque balance, three piece body design, easy to intall and repair Investment casting,casting passed Germany TUV certification in Material:CF8/CF8M/CF3/CF3M/WCB(customizable)
STANDARD SPECIFICATION
Pressure/Temperature: ASME B16.34 Design:ASME B16.34
Structure length:factory standard Test:API598
Connection:ASME BPE/ISO/IDF/DIN/3A/SMS
